360nm拉曼激光器

请选择规格

总计：0元

主要应用

LD泵浦的全固态、紫外激光在360海里全固态360 nm紫外线激光、特性的超紧凑、长寿命、成本有效性和简单的操作,这是用于DNA测序,流式细胞术,细胞分类,光学仪器,测量、物理实验、激光快速建模、拉曼光谱和荧光分析等。

360nm拉曼激光器

360/1~100mW - up to 100mW, 360 nm ultraviolet DPSS laser with TEM00 mode, high power stability

技术参数

Wavelength (nm)	360±1
Operating mode	CW
Output power (mW)	>1,10,20,… ,100
Power stability (rms, over 4 hours)	<5%, <10%
Transverse mode	Near TEM00
M2 factor	<2.0
Beam diameter at the aperture (1/e2, mm)	~1.5
Beam divergence, full angle (mrad)	<1.0
Polarization ratio	>100:1 Horizontal±5 degree (Vertical Optional)
Warm-up time (minutes)	<10
Beam height from base plate (mm)	27.4
Operating temperature (℃)	10~35
Power supply (90-264VAC)	PSU-H-LED	PSU-H-FDA
Expected lifetime (hours)	10000
Warranty	1 year

选型指南
